Russian TAL Refractors - Astronomical Refractor Telescopes by OVL

Buy ANY Sky-Watcher or TAL telescope from ANY UK dealer & buy this superb
Sky-Watcher Eyepiece, Filter, Night Vision Torch & User Guide Set for just £69.00 (SRP £149.00) directly from OVL!!

Kit Comprises: 2mm, 5mm, 15mm & 20mm Long Eye Relief Eyepieces, Four Threaded Light Filters (Amber, Blue, Neutral Grey & Moon Filter) Dual - Beam LED Night Vision Torch, Astronomical Telescope User Guide, in lockable, foam-padded Aluminium Case

Terms of Offer
Just send a photocopy of your receipt with a cheque (payable to OVL) and covering note to us at the address below. Order must be placed within FOUR MONTHS of telescope purchase. Please provide a daytime telephone number and an address, for guaranteed acceptance of delivery, between 9am-5pm Mon-Fri as the goods will be delivered by carrier. FREE delivery to any UK address!!

Offer commences 25th June 2007.
Telescope purchased 25/02/07 onwards qualify for offer.

Post to: Accessory Set Offer, Optical Vision Ltd, Unit 3 Woolpit Business Park, Woolpit, Bury St.Edmunds, Suffolk, IP30 9UP

(Please note: We reserve the right to discontinue this offer at any time without prior notice)

TAL-100RS (OTA)
100mm (4") f/10 Refractor Telescope

Magnification (with Optics Supplied) x40 & x155
Highest Practical Power (Potential): x250
Objective Lens Diameter: 100mm
Telescope Focal Length: 1000mm (f/10)
Eyepieces Supplied (1.25"): 6.3mm & 25mm Super Plossls
6x30 Finderscope
Rack & Pinion Focusing (1.25"/2")
Sky-Watcher compatible Tube Rings

	Prod. Code
TAL-100RS (OTA)	589	SRP £ 199.00

<BACK TO TOP OF PAGE>
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

TAL-100RS (EQ5)
100mm (4") f/10 Refractor Telescope

Magnification (with Optics Supplied) x40 & x155
Highest Practical Power (Potential): x250
Objective Lens Diameter: 100mm
Telescope Focal Length: 1000mm (f/10)
Eyepieces Supplied (1.25"): 6.3mm & 25mm Super Plossls
6x30 Finderscope
Rack & Pinion Focusing (1.25"/2")
Sky-Watcher compatible Tube Rings
EQ5 Deluxe Heavy-Duty Equatorial Mount
Built-in Polar Alignment Scope Holder
1.75" Stainless Steel Pipe Tripod with Accessory Tray

	Prod. Code
TAL-100RS (EQ5)	589/464	SRP £ 399.00

<BACK TO TOP OF PAGE>
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

TAL-100RS (EQ5 SynScan^TM)
100mm (4") f/10 Computerised GO-TO Refractor Telescope

Magnification (with Optics Supplied) x40 & x155
Highest Practical Power (Potential): x250
Objective Lens Diameter: 100mm
Telescope Focal Length: 1000mm (f/10)
Eyepieces Supplied (1.25"): 6.3mm & 25mm Super Plossls
6x30 Finderscope
Rack & Pinion Focusing (1.25"/2")
Sky-Watcher compatible Tube Rings
EQ5 SynScan ^TM Computerised GOTO Equatorial Mount (Requires 12 volt DC Power Supply)
Built-in Dual Axis Stepper Motors
Built-in Polar Alignment Scope Holder
1.75" Stainless Steel Pipe Tripod with Accessory Tray

Precision Computerised GO-TO Mount!!

	Prod. Code
TAL-100RS (EQ5 SynScan^TM)	589/981	SRP £ 0.00

<BACK TO TOP OF PAGE>
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

TAL-100RS (HEQ5)
100mm (4") f/10 Motorised Refractor Telescope

Magnification (with Optics Supplied) x40 & x155
Highest Practical Power (Potential): x250
Objective Lens Diameter: 100mm
Telescope Focal Length: 1000mm (f/10)
Eyepieces Supplied (1.25"): 6.3mm & 25mm Super Plossls
6x30 Finderscope
Rack & Pinion Focusing (1.25"/2")
Sky-Watcher compatible Tube Rings
HEQ5 Super Heavy-Duty Equatorial Mount
Built-in Dual Axis Motor Drives
Built-in Polar Alignment Scope Holder
1.75" Stainless Steel Pipe Tripod with Accessory Tray

Built-in Dual-Axis Motor Drive!!

	Prod. Code
TAL-100RS (HEQ5)	589/739	SRP £ 598.00

<BACK TO TOP OF PAGE>
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

TAL-100RS
(HEQ5 PRO SynScan^TM)
100mm (4") f/10 Computerised GOTO Refractor Telescope

Magnification (with Optics Supplied) x40 & x155
Highest Practical Power (Potential): x250
Objective Lens Diameter: 100mm
Telescope Focal Length: 1000mm (f/10)
Eyepieces Supplied (1.25"): 6.3mm & 25mm Super Plossls
6x30 Finderscope
Rack & Pinion Focusing (1.25"/2")
Sky-Watcher compatible Tube Rings
HEQ5 PRO SynScan^TM Super Heavy-Duty Computerised GOTO Equatorial Mount (Requires 12 volt DC Power Supply)
Built-in Dual Axis Stepper Motors
Built-in Polar Alignment Scope Holder
1.75" Stainless Steel Pipe Tripod with Accessory Tray

Precision Computerised GO-TO Mount!!

	Prod. Code
TAL-100RS (HEQ5 PRO SynScan^TM)	589/886	SRP £ 898.00

<BACK TO TOP OF PAGE>
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

HEQ5 SUPER HEAVY-DUTY
EQUATORIAL MOUNT

This heavy-duty mount is simply a scaled down version of the EQ6.
It is specially designed for observers who need similar steadiness of the EQ6 mount, but find the EQ6 too physically demanding.
Like the EQ6 mount, this high precision equatorial mount features engraved aluminium setting circles and a latitude scale, built-in polar scope holder and polarscope, large R.A. and DEC. locking clamps, built-in dual axis motor drives with multi-speed hand controller, and retractable counterweight shaft and counterweight. The field tripod is remarkably stable withadjustable height, incorporating 1.5" diameter steel tripod legs.

	Prod. Code
HEQ5 SUPER HEAVY-DUTY EQUATORIAL MOUNT	739	SRP £ 399.00

<BACK TO TOP OF PAGE>
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

HEQ5 SYNTREK^TM
Super Heavy-Duty Equatorial Mount

The new HEQ5 SynTrek is effectively a hybrid of the standard HEQ5 and the HEQ5 PRO SynScan. It is basically a standard EQ6 but with a pre-installed PRO SynScan motherboard and stepper motors, and supplied with its own unique SynTrek hand-controller.
The SynTrek hand control is designed for the purpose of providing a simple slewing and tracking control. The small and versatile SynTrek hand control provides automatic tracking of celestial objects as soon as the power is turned on. The user-friendly interface provides quick access to many other functions the SynTrek has to offer.
The HEQ5 and EQ6 SynTrek mounts can be upgraded to computerized SynScan system by simply changing the hand control to SynScan hand control (prod.code 948). See HEQ5 and EQ6 Pro mounts for specifications for the mounts and details on the SynScan hand control.

SynTrek Hand Control
Power supply: 11 to 15V DC 2Amp
Motor type and resolution: Microstep driven 1.8 stepper motors. Resolution: 0.144 arc sec (or 9,024,000 steps/rev.)
Slewing speeds: Guiding speed, 4x 8x, 32x, 64x, 800x
Guiding speeds: 1x, 0.75x, 0.5x, 0.25x
Gear ratio: 705
Tracking rates: Sidereal, Lunar, Solar
Tracking Modes: RA tracking

	Prod. Code
HEQ5 Syntrek^TM	850	SRP £ 549.00

<BACK TO TOP OF PAGE>
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

HEQ5 PRO SynScan^TM
GOTO Equatorial mount

For amateur astronomers seeking superior equatorial control and the ease of a precision computerized GOTO system, the HEQ5 PRO SynScan^tm is your answer. The Sky-Watcher HEQ5 PRO SynScan^tm is designed with the novice user in mind. With the user-friendly pushbutton hand control, locating and viewing the treasures of the night sky becomes as easy as a walk in the park. The hand control allows you to point the telescope at a specific object or even tour the skies at the touch of a button. The user-friendly menu system allows automatic slewing to over 13,400 objects. Even an inexperienced astronomer can master its variety of features in a few observing sessions. The HEQ5 PRO SynScan^tm also comes with features that advanced astronomers can appreciate:

Positioning Accuracy up to 1 arc minute. Accuracy enhanced by software collimation error (mount mechanical error) compensation. Stepper motors with 1.8° step angle and 64 micro steps driven. Slewing speed up to 3.4°/sec (800X). Auto Guider Interface for astro-photography. Power Supply Required - not supplied Guiding speed selectable from 0.25X, 0.50X, 0.75X, or 1X. Object database containing complete M, NGC, and IC catalogues. Minimal vibration for steady long-exposure photography.

"The Three-star alignment accurately corrects for cone error and subsequent GO-TO accuracy was impressive."
BBC Sky At Night Magazine

"I like these mounts, they are solid, well thought out and work quietly and effectively"
Astronomy Now Magazine

Related Manuals

	Prod. Code
HEQ5 PRO SynScan^TM	886	SRP £ 699.00

HEQ5 SynScan^TM GoTo Upgrade Kit

Available for easily upgrading the standard EQ5 mount for computerised GoTo capabilities. Comprises GoTo handset, Stepper Motors for Dec and R.A.Drives, Replacement Control Panel / Motor Board, Hand Control Cable, Cable Clamp, Hand Control Holder and Rechargable Power Supply Unit required - not supplied.

Product Code - 887

SRA: £439.00

<BACK TO TOP OF PAGE>
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

EQ6 DELUXE SUPER
HEAVY-DUTY EQUATORIAL MOUNT

The Sky-Watcher EQ6 equatorial mount is the first of its kind, and is top of our range of equatorial mounts. It is a precision instrument capable of carrying massive payloads (up to 25Kg) but at the same time is very reasonably priced. The mount is excellent for visual observations and short-term unguided CCD imaging with most telescopes of conventional design. It will easily handle refractors up to 8"/200mm and classic Newtonians up to 14"/350mm in aperture. The EQ6 has a black powder coat finish and weighs in at 17Kg.

The equatorial head features engraved aluminium setting circles and a latitude scale, a polar finder scope holder and polarscope, a bubble level, large R.A. and DEC. locking clamps, built-in dual axis motor drives and retractable counterweight shaft and counterweight. Two counterweights are supplied, each weighing 5.4Kg. The dual-axis motor drives are operated by a hand controller with a switch for both Northern and Southern hemisphere operation with slewing speeds of 2x, 8x and 16x the sidereal rate.

The tripod is made from 2" diameter stainless steel legs, making for a very sturdy system. The EQ6 (without telescope) adjusts from 1069mm in its lowest position to 1544mm with the tripod legs fully extended. The height of the mount (excluding tripod) is 406mm. The EQ6 accepts generic dovetail bars made by Sky-Watcher and many other companies.

	Prod. Code
EQ6 DELUXE SUPER HEAVY-DUTY EQUATORIAL MOUNT	740	SRP £ 599.00

<BACK TO TOP OF PAGE>
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

EQ6 SYNTREK^TM
Deluxe Super Heavy-Duty Equatorial Mount

The new EQ6 SynTrek is effectively a hybrid of the standard EQ6 and the EQ6 PRO SynScan. It is basically a standard EQ6 but with a pre-installed PRO SynScan motherboard and stepper motors, and supplied with its own unique SynTrek hand-controller.
The SynTrek hand control is designed for the purpose of providing a simple slewing and tracking control. The small and versatile SynTrek hand control provides automatic tracking of celestial objects as soon as the power is turned on. The user-friendly interface provides quick access to many other functions the SynTrek has to offer.
The HEQ5 and EQ6 SynTrek mounts can be upgraded to computerized SynScan system by simply changing the hand control to SynScan hand control (prod.code 948). See HEQ5 and EQ6 Pro mounts for specifications for the mounts and details of the SynScan hand control.

SynTrek Hand Control
Power supply: 11 to 15V DC 2Amp
Motor type and resolution: Microstep driven 1.8 stepper motors. Resolution: 0.144 arc sec (or 9,024,000 steps/rev.)
Slewing speeds: Guiding speed, 4x 8x, 32x, 64x, 800x
Guiding speeds: 1x, 0.75x, 0.5x, 0.25x
Gear ratio: 705
Tracking rates: Sidereal, Lunar, Solar
Tracking Modes: RA tracking

	Prod. Code
EQ6 SynTrek^TM	849	SRP £ 749.00

<BACK TO TOP OF PAGE>
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

EQ6 PRO SynScan^TM
GoTo Equatorial Mount

For amateur astronomers seeking superior equatorial control and the ease of a precision computerized GOTO system, the EQ6 PRO SynScan^TM is your answer. The Sky-Watcher EQ6 PRO SynScan^TM is designed with the novice user in mind. With the user-friendly pushbutton hand control, locating and viewing the treasures of the night sky becomes as easy as a walk in the park. The hand control allows you to point the telescope at a specific object or even tour the skies at the touch of a button. The user-friendly menu system allows automatic slewing to over 13,400 objects. Even an inexperienced astronomer can master its variety of features in a few observing sessions. The EQ6 SynScan^TM also comes with features that advanced astronomers can appreciate:

Positioning Accuracy up to 1 arc minute.
Accuracy enhanced by software collimation error (mount mechanical error) compensation.
Stepper motors with 1.8° step angle and 64 micro steps driven.
Slewing speed up to 3.4°/sec (800X).
Auto Guider Interface for astro-photography.
Guiding speed selectable from 0.25X, 0.50X, 0.75X, or 1X.
Object database containing complete M, NGC, and IC catalogues.
Minimal vibration for steady long-exposure photography.

Specifications

Power Supply Required: 12 VDC 2Amp Tip positive (not supplied)
Motor Type: Micro step driven 1.8° stepper motors
Resolution: 0.144 arc sec (or 9,024,000 steps/rev.)
Slew Speeds: 2X, 8X, 16X, 32X, 64X, 400X, 500X, 600X, 800X Gear Ratio: 705
Tracking Rate: Sidereal, Lunar, Solar
Tracking Modes: Dual Axis, R.A. Tracking
Alignment Methods: One-star Alignment, Two-star Alignment, Three-star Alignment
Database: 25 user defined objects. Complete M, NGC, and IC catalogues. Total 13,436 objects.

Mount Specifications

Mount Type: German Equatorial
Telescope Mounting: Tube Rings
Slow-motion Control: R.A. & Dec (motor controlled)
Tripod: 2" Diameter Stainless Steel Pipe
Tripod Height: 85-147cm
Tripod Weight: 7.5Kgs
Counterweight Shaft Daimeter: 1.8cm
Counterweight Shaft Material: Stainless Steel
Mount Weight: 16Kgs
Mount Height: 41cm
Counterweight: Two, 5.1Kgs each
Total Weight: 23.5Kgs (counterweight not included)

"Best for heavy scopes".... "We practically had to thump it to induce any vibrations"
BBC Sky At Night Magazine

"I like these mounts, they are solid, well thought out and work quietly and effectively"
Astronomy Now Magazine

Related Manuals

	Prod. Code
EQ6 PRO SynScan^TM	854	SRP £ 899.00

HEQ6 SynScan^TM GoTo Upgrade Kit

Available for easily upgrading the standard EQ6 mount for computerised GoTo capabilities. Comprises GoTo handset, Stepper Motors for Dec and R.A.Drives, Replacement Control Panel / Motor Board, Hand Control Cable, Cable Clamp, Hand Control Holder and Rechargable Power Supply Unit required - not supplied.

Product Code: 851

SRA: £499.00

<BACK TO TOP OF PAGE>
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

The prices listed on this website are U.K. suggested retail prices (SRP) including VAT for reference purposes only
and that prices may vary from dealer to dealer. Please contact your nearest stockist for firm pricing information.
As we are purely a distributor, we regret we are unable to sell directly to the public.
Specifications subject to variation due to later production changes. E&OE.
